Shall be a hydraulically operated flail head 60 inches long, fitted with a tubular shaft. The 60” head shall have 40 flail stations and shall be fitted with drop-forged double-edged flails capable of cutting and mulching grass and branches up to 4” in. diameter.
Shall have ¼” high grade steel side plates, heavy duty 3/16” high grade steel cowling, 3/8” all rotor shaft, 6” pivoting roller, built in wire safety guard, fully adjustable front guard and rear full length rubber flap for debris containment.
Unit shall also have 50mm heavy duty rotor shaft bearings, twin speed rotor shaft (2400/3000 RPM), top mounted cast iron motor, triple belt drive and full slide mount feature.
An adjustable metal roller, six inch diameter (minimum), to give cutting heights between 3/4 inch and 3 inch with regreasable sealed bearings shall be fitted at the rear of the cowl.
Rotor shaft shall be driven by a hydraulic motor with three matched V-belts and grooved pulleys. Rotor shaft rotation shall be clockwise and counter clockwise, with a speed of 2200 to 2900 RPM.
